Statistics Card 3 min read RosCard YAML

RosCard Statistics Card Guide

Configure the RosCard Statistics Card to monitor and track device status directly from your Astrion Remote. Get real-time counts of active lights, switches, and climate devices in any zone or room.

Last updated: July 2026 Requires: RosCard installed Light, Switch, Climate monitoring

Overview

The RosCard Statistics Card provides a dedicated monitoring interface for tracking device status on your Astrion Remote. Unlike other RosCard cards that control devices, the Statistics Card is designed to monitor and display the state of multiple devices in a single view.

The Statistics Card supports tracking of Lights, Switches, and Climate devices, displaying real-time counts of active devices in any zone or room. It's perfect for getting a quick overview of your smart home's status.

💡 Tip: The Statistics Card is read-only — it displays device states but does not allow toggling. For device control, use the dedicated Light Card, Switch Card, or Climate Card.

Features

💡

Light Monitoring

Track active and inactive light states in any zone

🔘

Switch Monitoring

Monitor switch and relay states

🌡️

Climate Monitoring

Track HVAC mode and state per zone

📊

Real-Time Counts

Instant visibility into active devices per category

📱

Independent Display

Full-screen dedicated view for quick status checks

Step-by-Step Configuration

1 Open Dashboard Editor

In Home Assistant, navigate to the dashboard you want to use for your Astrion Remote. Click Edit Dashboard in the top-right corner.

2 Add Statistics Card

Click Add Card and search for "Statistics (ROS)" or "custom:aiks-switch-monitor-card". Select it to add the card to your dashboard.

3 Configure Device Types

Enable the device types you want to monitor. The Statistics Card supports Light, Switch, and Climate devices.

Example Configuration:

type: custom:aiks-switch-monitor-card uuid: a58ddbb5-84a4-424e-b712-81f4cac69c4b monitor_name: home device_types: light: true switch: true climate: true

4 Configure Monitor Name

The monitor_name parameter allows you to label your statistics view — for example, "Living Room", "Bedroom", or "Home".

5 Enable Independent Display

For any card you want to appear as a full-screen view on your Astrion Remote, enable Independent Display.

6 Save and Refresh

Click Save to apply your configuration. On your Astrion Remote, pull down from the top of the home screen and tap Refresh to load the new card.

⚠️ Important: The Statistics Card only monitors devices from the same Home Assistant instance. Ensure your Astrion Remote is properly connected to Home Assistant for accurate status updates.

YAML Reference

Full Parameter List

type: custom:aiks-switch-monitor-card uuid: string # Required: Unique identifier monitor_name: string # Display name for the monitor device_types: light: true # Enable light monitoring switch: true # Enable switch monitoring climate: true # Enable climate monitoring

Parameter Details

uuid — A unique identifier for the card. Generated automatically when you add the card.
monitor_name — A custom name for the statistics view (e.g., "Living Room", "Home").
device_types — Enable or disable monitoring for each device type.

Monitoring Device Types

Light (light): Tracks all light entities in Home Assistant.
Switch (switch): Tracks all switch entities in Home Assistant.
Climate (climate): Tracks all climate entities in Home Assistant.

💡 Tip: The Statistics Card automatically counts devices by state — for lights and switches, it shows the number of devices that are on vs. off. For climate devices, it shows the number of devices in heating, cooling, or idle mode.

Example Use Cases

Room Status Overview

type: custom:aiks-switch-monitor-card uuid: a58ddbb5-84a4-424e-b712-81f4cac69c4b monitor_name: Living Room device_types: light: true switch: true climate: true

Get a quick status overview of your living room — how many lights are on, which switches are active, and whether the climate system is running.

Entire Home Dashboard

type: custom:aiks-switch-monitor-card uuid: 3d43a7c3-1957-4bcf-a34c-911aac62189d monitor_name: Home device_types: light: true switch: true climate: true independent_display: true

Monitor your entire home's status at a glance. Perfect as a home screen card on your Astrion Remote.

Energy-Aware Zone Monitoring

type: custom:aiks-switch-monitor-card uuid: 8fd848c5-78a1-41dc-bbf7-43b965bfe463 monitor_name: Office device_types: light: true switch: true climate: false

Monitor lights and switches only in your office, tracking energy usage and ensuring devices aren't left on unnecessarily.

Troubleshooting

Statistics Card Not Showing on Astrion Remote

Refresh the remote: Pull down from the top of the home screen and tap Refresh.
Verify card configuration: Ensure the YAML configuration is valid and saved.
Check entity types: Make sure you have at least one entity of the enabled device types in Home Assistant.
Update RosCard: If you're running an older version, update RosCard via HACS.

No Data Displayed

Verify entities exist: Ensure you have lights, switches, or climate entities in Home Assistant.
Check device_types: Verify the correct device types are enabled in your configuration.
Wait for update: The card may take a moment to populate data after initial configuration.
Restart Home Assistant: If issues persist, try restarting Home Assistant.

Incorrect Device Counts

Verify that the entities in Home Assistant are correctly categorized as light, switch, or climate.
Check for duplicate or hidden entities that may affect counts.
Refresh the card view on your Astrion Remote.

Climate Data Not Showing

Ensure climate: true is set in your configuration.
Verify you have climate entities in Home Assistant.
Check that your climate entities are reporting state correctly in Home Assistant Developer Tools.

🔧 Note: After updating RosCard to a new version, you may need to resave your Statistics Card to refresh the binding. This is a known requirement for version updates.
