Create Macros on Astrion Remote
Learn how to create Macros on your Astrion Remote — sequences of actions triggered by a single button press. This guide covers Movie Night, Normal TV, and All Off macros with ready-to-use YAML templates for Home Assistant.
What Are Macros?
A Macro is a sequence of actions triggered by a single button press on your Astrion Remote. Instead of performing multiple steps manually, you press one button and everything happens automatically:
- 🎬 Start Movie → dim lights + warm color + TV on + set input
- 📺 Normal TV → balanced lighting + TV on
- 💤 All Off → TV off + lights off
📌 Prerequisites: Before creating Macros, make sure you have:
• Astrion Remote firmware v1.4.0 or newer
• ROSCard v1.4.0 or newer (installed via HACS)
• Home Assistant Scenes already created
• Your device entity IDs (TV, lights) noted down
Finding Your Entity IDs
Before creating Macros, you need the exact entity IDs for your devices. Here's how to find them:
Samsung TV
1 Go to Settings → Devices & Services → Integrations
2 Click your Samsung TV integration
3 Click the TV device → look at the Entities list
You'll see something like:
media_player.living_room_samsung_tvmedia_player.samsung_tv_qn65q80b
That full string is your TV entity ID.
Philips Hue Lights
1 Go to Settings → Devices & Services → Entities
2 Filter by Domain: light
3 Look for entries matching your room/zone names
You'll see entities like:
light.living_room(Hue room group)light.cinema_zone(Hue zone group)
For macros, use the group entity (room or zone), not individual bulbs.
💡 Hue Groups: Make sure "Allow Hue groups" / "Import rooms and zones" is enabled in your Hue integration settings. This makes room/zone groups available as single entities.
Step 1 — Open Macro Configuration
1.1 On Your Astrion Remote
Open the Astrion App (main screen application) and navigate to Macros & Automation or Shortcut Configuration.
1.2 Alternative — Via TV Card
Macros can also be created in the TV Card configuration in Home Assistant. In the TV Card settings, select your Astrion remote model (found in Astrion App → Settings → About) to see available physical buttons.
1.3 Add a New Macro
Click Add Macro to create your first automation.
Step 2 — Create "Start Movie" Macro
This macro turns on your TV, sets the correct input, and activates the Movie Night scene.
| Setting | Value |
|---|---|
| Macro Name | Start Movie |
| Trigger Button | Colored Button 1 — Short Press |
Actions (in order):
| # | Service | Target | Data |
|---|---|---|---|
| 1 | scene.turn_on |
scene.movie_night |
— |
| 2 | media_player.turn_on |
media_player.YOUR_TV_ENTITY |
— |
| 3 | media_player.select_source |
media_player.YOUR_TV_ENTITY |
source: "HDMI 2" |
✅ Macro Created! Button 1 will now start your movie mode.
Step 3 — Create "Normal TV" Macro
This macro turns on your TV with default settings and activates the Normal TV scene.
| Setting | Value |
|---|---|
| Macro Name | Normal TV |
| Trigger Button | Colored Button 2 — Short Press |
Actions (in order):
| # | Service | Target | Data |
|---|---|---|---|
| 1 | scene.turn_on |
scene.tv_normal |
— |
| 2 | media_player.turn_on |
media_player.YOUR_TV_ENTITY |
— |
| 3 | media_player.select_source |
media_player.YOUR_TV_ENTITY |
source: "TV" |
Step 4 — Create "All Off" Macro
This macro turns off your TV and lights with a single press.
| Setting | Value |
|---|---|
| Macro Name | All Off |
| Trigger Button | Colored Button 3 — Short Press |
Option A — Using Scene
| # | Service | Target |
|---|---|---|
| 1 | media_player.turn_off |
media_player.YOUR_TV_ENTITY |
| 2 | scene.turn_on |
scene.all_off |
Option B — Direct Light Control
| # | Service | Target |
|---|---|---|
| 1 | media_player.turn_off |
media_player.YOUR_TV_ENTITY |
| 2 | light.turn_off |
light.YOUR_HUE_GROUP |
Advanced: Short Press vs Long Press
Each button can be configured with different actions for short press and long press — doubling your available buttons without adding hardware.
| Button | Short Press | Long Press |
|---|---|---|
| Button 1 | Start Movie | Pause / Resume |
| Button 2 | Normal TV | Switch Input |
| Button 3 | All Off (Room) | All Off (Whole House) |
💡 Tip: In the macro configuration, each button has separate Short Press and Long Press trigger options. Set them up to create a more powerful remote experience.
Global Button Behavior
The Global Button Behavior setting controls how physical buttons behave in different contexts on your Astrion Remote.
| Setting | Behavior |
|---|---|
| Enabled | Global shortcut mapping works everywhere on the remote |
| Disabled |
Inside TV interface → Follows TV Card mappings
Outside TV interface → Follows global shortcut settings |
💡 Recommendation: If you want buttons to behave differently when controlling your TV vs. navigating the main interface, disable Global Button Behavior.
Step 5 — Sync to Your Astrion Remote
1 Open Remotios / Sync
On your Astrion Remote, open the Remotios / Sync function.
2 Select Your Dashboard
Select the dashboard you want to sync (e.g., "Astrion Pro" or your custom dashboard).
3 Complete the Sync
Click Sync and wait for the configuration to transfer.
4 Test Your Macros
Press each button to verify the macros work as expected:
- 🔘 Button 1 → Movie scene + TV on + input set
- 🔘 Button 2 → Normal TV scene + TV on
- 🔘 Button 3 → TV off + lights off
✅ All Done! Your Astrion Remote is now configured with one-button automation. Next, learn how to create Activities to combine macros with custom screen layouts.
Troubleshooting
Macro Doesn't Execute
- Check that the entity IDs are correct
- Verify that the scene exists in Home Assistant
- Confirm your TV integration is working in Home Assistant
Button Does Nothing
- Verify firmware is v1.4.0 or newer
- Check that ROSCard is v1.4.0 or newer
- Re-sync the remote after making changes
TV Doesn't Respond
- Check that the TV entity ID is correct
- Verify the TV is on the same network as Home Assistant
- Check the source name in the
select_sourceaction
Lights Don't Change
- Check the light group entity ID is correct
- Verify the scene is saved in Home Assistant
- Test the scene manually in Home Assistant first
Sync Fails
- Check the network connection between the remote and Home Assistant
- Restart Home Assistant and try again
- Check the official support thread for known issues
🔧 Still Not Working? Please create a forum post and include:
• Your firmware version
• Your ROSCard version
• The exact macro configuration
• Any error messages
